Platform Type Dispersing Vessel

The Platform Dispersing Vessel is a high-performance industrial equipment that integrates the functions of a mixing vessel and a high-speed disperser into a single, space-efficient unit. As the name suggests, the entire system—including the vessel, dispersing mechanism, and auxiliary components—is securely mounted on a sturdy platform. This design is specifically engineered for large-batch, continuous industrial production, making it an ideal solution for manufacturers seeking to scale up their operations with enhanced efficiency, safety, and process control.

Also referred to as a mezzanine disperser or platform-mounted dispersing machine, this equipment is widely adopted in industries such as paints, coatings, inks, adhesives, chemicals, cosmetics, pharmaceuticals, and food processing.

Online consultation Download

Description

The Platform Dispersing Vessel represents a robust, scalable, and highly efficient solution for industrial‑scale dispersion and mixing operations. By combining the functions of a mixing vessel and a disperser in a fixed platform configuration, it delivers exceptional throughput, operational flexibility, and process reliability—making it the equipment of choice for manufacturers aiming to achieve high‑volume production with consistent quality. With extensive customization options and proven performance across multiple industries, it is a versatile workhorse for modern production facilities.

Features

Frequency Inverter Drive;

Vacuum / Sealed Option;

High‑Speed Dispersing Disc;

Jacket Optional

One Machine, Multiple Vessels – Optional;

Applications

The Platform Dispersing Vessel is suitable for the dissolution, mixing, dispersion, and emulsification of materials across a wide viscosity range (up to 10,000 cps).

Typical applications include:

Paints & Coatings: Latex paints, industrial coatings, decorative paints, automotive paints, wood finishes
Inks: Water‑based inks, solvent‑based inks
Adhesives & Sealants: Glues, binders, resin systems
Chemicals: Dyes, pigments, fertilizers, detergents
Cosmetics & Personal Care: Creams, lotions, pastes
Pharmaceuticals & Biotechnology: Suspensions, emulsions
Food Processing: Sauces, pastes, liquid food products
Energy: Battery slurries, advanced material dispersions

Competitive Advantage

Massive Processing Capacity

The platform design supports vessel volumes ranging from 50 liters up to 30,000 liters or more, accommodating the most demanding production requirements. This makes it the preferred choice for high-throughput manufacturing lines.
Enhanced Safety and Stability.

Unlike mobile or floor‑standing units, the platform‑mounted vessel is fixed in place, eliminating risks associated with tipping or accidental displacement. Electrical systems can be equipped with flameproof (explosion‑proof) components to ensure safe operation in hazardous environments.
Optimized Material Handling & Workflow

The platform design positions the vessel opening at an ergonomic height, simplifying raw material loading. The bottom discharge configuration, often combined with pumping systems, enables rapid, residue‑free product transfer. The system can also be integrated with automated batching and dosing systems for precise recipe control.

Specifications

Model	Disperser Power(kW)	Disperser Speed (rpm)	Processing Capacity (L)	Disc Diameter(mm)
RMFS-11	11	0-1440	100-400	250
RMFS-15	15	0-1440	150-500	300
RMFS-18.5	18.5	0-1440	200-800	300
RMFS-22	22	0-1440	200-1000	300
RMFS-30	30	0-1440	300-1500	350
RMFS-37	37	0-1440	400-2000	400
RMFS-45	45	0-1440	500-2500	450
RMFS-55	55	0-1200	600-3000	450
RMFS-75	75	0-1200	800-4000	500
RMFS-90	90	0-960	1000-5000	550
RMFS-110	110	0-960	1000-6000	550

The motor power and speed wll be customzied as the material property and customer's needs. Above informationis just for your reference. For more accurate information, please feel free to contact us!
